Notes003: Clipping Audio Through Mixers

2024/09/05|

• #ガイド
• #Modular Synthesizer
• #Mixer（ミキサー）
• #AI Synthesis
• #ADDAC System

A column about how clipping audio can actually sound great. Explains what clipping means and how different mixers produce different results.

ADDAC System: ADDAC713 Stereo Discrete Mixer

2024/08/28|

• #ADDAC System
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the ADDAC713 Stereo Discrete Mixer. The ADDAC713 is a compact yet feature-rich stereo mixer. It features 3 stereo input channels with Pan control and 1 mono input channel, mixing them together. Each channel and the master output have dedicated gain knobs for flexible volume adjustment. Additionally, it includes a hard clipping function for the input sources, producing dramatic tonal changes. In other words, it can be described as a stereo mixer with built-in hard distortion capabilities.

AI Synthesis: AI022 Harmonic Mixer

2024/07/14|

• #AI Synthesis
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the AI Synthesis AI022 Harmonic Mixer. The AI022 Harmonic Mixer is a mono 3-channel mixer module. As you increase the gain, it enriches the harmonics and adds warmth and distortion to the input audio signal.

AI Synthesis: AI106 West Coast Mixer

2024/07/14|

• #AI Synthesis
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the AI Synthesis AI106 West Coast Mixer. The AI106 is a mono 3-channel mixer module that incorporates mixer design elements from vintage West Coast synthesizers, adding character and harmonic changes to input waveforms.

ADDAC System: ADDAC216 Sum & Difference

2024/05/23|

• #ADDAC System
• #Modular Synthesizer
• #utility
• #Mixer（ミキサー）

An introduction to the ADDAC System ADDAC216 Sum & Difference. The ADDAC216 is essentially a two-section mixer, but this two-section mixer is capable of diverse CV synthesis processing. Each section has two CV input jacks, offering individual CV Attenuvert, mixing of two CVs, Full Wave Rectification, AC coupling, signal inversion, and average calculation -- all in a single module.

AI Synthesis: AI008 Eurorack Matrix Mixer

2024/04/14|

• #AI Synthesis
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the AI Synthesis AI008 Eurorack Matrix Mixer. The AI008 is a 4-input, 4-output matrix mixer. DIY kits are also available.

AI Synthesis: AI018 Stereo Matrix Mixer

2024/04/14|

• #AI Synthesis
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the AI Synthesis AI018 Stereo Matrix Mixer. The AI018 is an 8-input, 8-output matrix mixer that allows flexible routing of each input to any output. DIY kits are also available.

NoisyFruitsLab: 5MX Mixer

2024/01/13|

• #NoisyFruitsLab
• #Modular Synthesizer
• #Mixer（ミキサー）

An introduction to the NoisyFruitsLab 5MX Mixer. The 5MX Mixer is a simple 5-channel mixer.
